Gương phản xạ Ophir cho máy cắt laser CO2

Posted on Posted in Linh kiện quang học Ophir

quy trinh guong phan xa





Loại gương Lớp phủ Mô tả Code
Zero Phase Shift Si ZPS Dia. 3.0″ ET. 0.25″ Reflection / Abs. 10.6 Micron > 99.5% OP801101
Zero Phase Shift Cu ZPS Dia. 2.36″ ET. 0.591″ Reflection 10.6 Micron > 99.5% OP801102
90 degree Phase Shift Si 90PR Dia. 3.0″ ET 0.25″ Reflection /Abs. 10.6 Micron > 98% OP801201
90 degree Phase Shift Cu 90PR Dia. 50mm ET 10mm Reflection /Abs. 10.6 Micron > 99% OP801202
90 degree Phase Shift Cu 90PR Dia. 1.5″ ET 0.25″ Reflection /Abs. 10.6 Micron > 98% OP801203
90 degree Phase Shift Cu 90PR Dia. 3.0″ ET 15mm Reflection /Abs. 10.6 Micron > 98% OP801204
Telescopic Cu MMR Dia. 50mm 1.4MCX ET. 10mm Reflection / Abs. 10.6 Micron > 99.8% OP801401
Telescopic Cu MMR Dia. 50mm 2MCC ET. 10mm Reflection / Abs. 10.6 Micron >
99.8%
OP801402
ATFR Cu ATFR Coating ATFR Dia. 50mm ET. 25mm OP801501
ATFR Cu ATFR Coating ATFR Dia. 60mm ET. 15mm OP801502
End Mirrors Ge Rear Miror Coating 99.5% Dia. 1.1″ 10MCC/0.6MCX ET. 0.22″ OP801601
End Mirrors Ge Rear Miror Coating 99.5% Dia. 1.1″ 20MCC/Plano ET. 6.0mm OP801602
Total Reflection Si Total Reflector Coating MMR-P Dia. 1.5″ ET. 5.10mm Reflection / Abs.
10.6 Micron > 99.8%
OP801701
Total Reflection Cu Total Reflector Coating MMR Dia. 60mm ET. 10mm Reflection / Abs.
10.6 Micron > 99.8%
OP801702
Total Reflection Cu Total Reflector Coating MMR Dia. 50mm ET. 10mm Reflection / Abs.
10.6 Micron > 99.8%
OP801703
Total Reflection Si Total Reflector Coating MMR Dia. 1.75″ ET. 0.375″ Reflection / Abs.
10.6 Micron > 99.8%
OP801704
Output Couplers ZnSe Coating 60% Dia. 1.1″ 10MCC/7.5MCX ET. 0.22″ Reflection / Abs. 10.6
Micron < 0.10%
OP801801
Output Couplers ZnSe Coating 70% Dia. 1.1″ Plano/Plano ET. 6.00mm Reflection / Abs. <
0.12%
OP801802
Output Couplers ZnSe Coating 50% Dia. 1.18″ PO/PO ET. 0.236″ Reflection / Abs. 10.6
Micron < 0.10%
OP801803
