Electronic controller Hansan (HSM-H)
* Dueto the possible usage of VVVF function, it has solved the problem which usershad to adjust the frequency by the pan spring when using the electronicoscillator.
* Ableto use the output generated by the external control as the ON/OFF control,contact control and voltage control (12-24DCV) and it is designed as to controlthe contact signal with the various equipments synchronously. Also, by using the function settingparameter, it can be set as considering the work environment and condition andit can fully bring out the work productivity and convenience. Please read through the manual beforeoperating the controller and magnetic feeder so that users can fully use theexcellent functions of Magnetic Feeder properly.
* Characteristic
– Wide input voltage range
– Compact design
– Feedback function
– Protectthe circuit from heating
– Various function built in
– Protectivefunction from the external vibration
|
list |
HSM-H10 |
HSM-H30 |
HSM-H60 |
|
|
drive source |
PWM method |
|||
|
input |
Voltage(AC) |
85V-265V |
||
| Frequency |
60 / 50Hz |
|||
|
output |
Amperage(A) |
1A |
5A |
10A |
| Voltage(AC) |
0~110V [when input voltage is 110V] 0~220V [when input voltage is 220V] |
|||
| Frequency |
40Hz ~ 400Hz(setting parameter) |
|||
| control | externalinput ON/OFF control method |
voltage(DC12V ~ DC24V), Junction |
||
| OVF sensor input temporal stop control |
Temporal stop/Run (Over flow) in RUN state |
|||
| control method |
Digital control method by the RISC CPU |
|||
| protective function |
over vibration/over heat/Fan error/Sensor Error |
|||
| cooling method |
cooling method by using the heat sink and dc fan |
|||
| ambient temperature |
0℃~40℃ (however icing now allowed) |
|||
| ambient humidity |
10 ~ 90% (however dew condensation now allowed) |
|||
| coating color |
Pantone Color 428C |
|||
