Temperature sensors – Compact transmitters for the food and beverage industry

Posted on admin2Posted in , Ifm sensos, electronic system
Product Measuring range temperature Factory setting Analogue output Process connection Installation length EL
TA2531 -50…200 °C -10…150 °C 4…20 mA G 1/2 sealing cone 100 mm
TA2511 -50…200 °C -10…150 °C 4…20 mA G 1/2 sealing cone 50 mm
TA2232 -50…200 °C 0…200 °C 4…20 mA diameter Ø 6 mm 100 mm
TA2242 -50…200 °C 0…200 °C 4…20 mA diameter Ø 6 mm 150 mm
TA1321 -50…200 °C -10…150°C 4…20 mA G 3/8 internal thread 83 mm
TA2502 -50…200 °C 0…200 °C 4…20 mA G 1/2 sealing cone 30 mm
TA2262 -50…200 °C 0…200 °C 4…20 mA diameter Ø 6 mm 250 mm
TA2241 -50…200 °C -10…150 °C 4…20 mA diameter Ø 6 mm 150 mm
TA2812 -50…200 °C 0…200 °C 4…20 mA Clamp 1,5″ 50 mm
TA1327 -50…200 °C 0…100°C 4…20 mA G 3/8 internal thread 83 mm
TA1322 -50…200 °C 0…200°C 4…20 mA G 3/8 internal thread 83 mm
TA2537 -50…200 °C 0…100 °C 4…20 mA G 1/2 sealing cone 100 mm
TA1101 -50…200 °C -10…150°C 4…20 mA M12 x 1,5 sealing cone 17 mm
TA1102 -50…200 °C 0…200 °C 4…20 mA M12 x 1,5 sealing cone 17 mm
TA1107 -50…200 °C 0…100 °C 4…20 mA M12 x 1,5 sealing cone 17 mm
TA2292 -50…200 °C 0…200 °C 4…20 mA diameter Ø 6 mm 350 mm
TA2517 -50…200 °C 0…100 °C 4…20 mA G 1/2 sealing cone 50 mm
TA2512 -50…200 °C 0…200 °C 4…20 mA G 1/2 sealing cone 50 mm
TA2002 -50…200 °C 0…200 °C 4…20 mA Clamp 3/4″ 25 mm
TA2212 -50…200 °C 0…200 °C 4…20 mA diameter Ø 6 mm 50 mm
TA2532 -50…200 °C 0…200 °C 4…20 mA G 1/2 sealing cone 100 mm
TA2542 -50…200 °C 0…200 °C 4…20 mA G 1/2 sealing cone 150 mm
TA2012 -50…200 °C 0…200 °C 4…20 mA Clamp 3/4″ 60 mm
TA2802 -50…200 °C 0…200 °C 4…20 mA Clamp 1,5″ 30 mm
