EDM 와이어 커팅 기계 용 전도성 시트 Mitsubishi
| 급전 접점 | |||||
| 그림 | 코드 번호 | Orignal P/No. | 치수 | 위치 | 신청 |
 |
M001 | X054D125H03 | Φ7xΦ0.7×22 Φ7xΦ0.8×22 |
Common | DWC-N. F. G. H. HA. C series Manual type |
 |
M001 S | 5H03 | Φ7xΦ0.7×22 Φ7xΦ0.8×22 |
Common | DWC-N. F. G. H. HA. C series Manual type Screw type |
 |
M002 | X054D129H04 | Φ7xΦ0.7×22 Φ7xΦ0.8×22 |
Lower | DWC-N. G. H. HA. SA. SB series |
 |
M002 S | X054D129H04 | Φ7xΦ0.7×22 Φ7xΦ0.8×22 |
Lower | DWC-N. G. H. HA. SA. SB series SK1.2.3. AF1 type Screw type |
 |
M003 | X054D199H01 | Φ3.0xΦ0.7×16 | Upper | DWC- F. F1. G series SK1. AF type / Upper B |
 |
M004 | X054D216H01 | Φ3.0xΦ0.7×16 | Upper | DWC- F. F1. G series SK1 type / Upper A |
 |
M005 | X054D345H01 | 2.5×3.0x27.5 | Upper | DWC-B. H1. HA. PA. SA. SB. SZ – AF1 type DWC-H. G series – SK2.3 type |
 |
M005 G | X054D345H01 | 2.5×3.0x27.5 | Upper | DWC-B. H1. HA. PA. SA. SB. SZ – AF1 type DWC-H. G series – SK2.3 type |
 |
M008 | X054D186H03 | 1.0×6.0x8.0 | Common | DWC-H1. HA sereies Manual type |
 |
M009 | X056C075H01 X056C075H04 |
Φ24.8 x 20 | Common | DWC-HA. SA. SB. SZ. SX. CX. QA. RA series DWC-FX. FA series AT. AF2.3 type /Polishedstandardtype |
 |
M009-1 | X056C432H01 X056C075H06 |
Φ24.8x 20 | Common | DWC-HA. SA. SB. SZ. SX. CX. QA. RA series DWC-FX. FA series / AT. AF2.3 type Ref. M009N / Unpolishedstandardtype |
 |
M009-2 | X056C075H05 | Φ24.8x 20 | Common | DWC-CX. FA. FX-S series AT. AF1.2.3 type/ Polishedangletype |
 |
M009-3 | X056C075H05 | Φ24.8x 20 | Common | DWC-CX. FA. FX-S series AT. AF1.2.3 type/ Unpolishedangletype |
 |
M009V | X055C118H02 | Φ24.8x 20 | Common | DWC-FA-V series AT. AF1.2.3 type/ Polishedtype |
 |
M009V1 | X055C118H02 | Φ24.8x 20 | Common | DWC-FA-V series AT. AF1.2.3 type/ Unpolishedtype |
| 급전 접점 | |||||
| 그림 | 코드 번호 | Orignal P/No. | 치수 | 위치 | 신청 |
 |
M009A | X059D448G52 | Common | DWC-N. F. G. H. HA. C series Plastic pin for M009 |
|
 |
M010S | X088D439H01 | 5x18x38 | Common | DWC-BA series |
