Multi-connector/Rectangular Multi-connector (DM/KDM) SMC

Posted on Posted in Air Fitting - Speed controller

Series: DM, KB, KC, KDM, KM, KRM, M



Go To DM

DM, Series PDF



DM

The use of the DM series, multi-connector, enables panel mount connections with other apparatus and can provide the reliability of one-touch installation and removal of multi-tubes (nylon, polyurethane). As a result, separate transportation of panel and machinery equipment and backup unit exchange is made possible.

Go To KDM

KDM, Series PDF



KDM

Rectangular multi-connector series KDM has substantial reduction in mounting space in comparison with a model requiring many union joints for panels and partitions, this model needs only a small space. KDM is suitable for use with positive pressure and vacuum. It is possible to create a multi-connector with mixed tube sizes.

Go To KM

KM, Series PDF

KM

One-touch fitting manifold series KM has 6 different model options available. Male thread and female thread options available on certain models. Tube material includes nylon, soft nylon and polyurethane.

Go To KRM

KRM, Series PDF

KRM

Series KRM is a flame resistant, one-touch fittings manifold (equivalent to UL-94 standard V-0). Compact and manifold piping is possible. There are many varieties (8 different styles) available.

Go To KB

KB, Series PDF

KB

Piping module series KB has made distribution easy utilizing one-touch fittings. A locking system makes the use of tools unnecessary for installation of one- touch fittings and makes piping more efficient. Universal construction allows for changes in air output direction after connections are completed.
