Mold change cart MICO
A cart is used to change the large – sized and standard molds in a large injection molding machine.
A single cart is generally fixed on the side of an injection molding machine or press for one-wey or two-way operation. A cart is driven by roller or hook (option).
Compatible with an injection molding machine, and allows an easy operation for a quick mold change. It is commonly used, because the preparation can safely be conducted even if an injection molding machine or press is in operation. One cart can cover two machines to increase the economical efficiency and maximize the space utilization.
A remote control is introduced to ensure a safety and visibility (option).
| Type | Loading
Capacity |
Model | Size (W*L*H) | Mold spec | |||
| W | L | H | MokJ tickness (MAX) | Mold length | |||
| 10 Ton | MIF-1S-10 | 1,800 | 2,500 | 1,100 | 1,630 | 1600-1900 | |
| Single Fixed | 20 Ton | MIF-1S-20 | 2,070 | 3,200 | 1,250 | 1,700 | 1600-2200 |
| 30 Ton | MIF-1S-30 | 2,260 | 3,500 | 1,500 | 1,850 | 1600-2700 | |
| 2×20 Ton | MID-1S-2X20 | 5,400 | 2,900 | 1,250 | 1,700 | 1600-2200 | |
| Double Moving | 2×30 Ton | MID-1S-2X30 | 6,000 | 2900+6COlBridge table) | 1,550 | 1,850 | 1600-2500 |
| 2x40Ton | MID-1S-2X40 | 6,000 | 29GQ+oG0lBridge table) | 1,670 | 1,950 | 1600-2700 | |
