Through-hole long stroke power chuck Kitagawa BL-200 series
기술:
매우 긴 턱 스트로크
단단히 잡은 플랜지 작업
기술 사양 :
| Model | BL-206 | BL-208 | BL-210 | BL-212 | ||
|---|---|---|---|---|---|---|
| Through-hole (mm) | 28 | 45 | 53 | 63 | ||
| Gripping Range (mm) | Max. | 165 | 215 | 254 | 304 | |
| Min. | 24 | 26 | 33 | 36 | ||
| Jaw Stroke (Diameter) (mm) | 20 | 25 | 30 | 35 | ||
| Plunger Stroke (mm) | 15 | 19 | 22 | 25 | ||
| Max. Draw Bar Pull Force (kN) | 27.9 | 41.1 | 53.8 | 69.3 | ||
| Max. Static Gripping Force (kN) | 31.2 | 49.0 | 63.0 | 80.4 | ||
| Max. Speed (min-1) | 4500 | 3300 | 3000 | 2200 | ||
| Moment of Inertia (kg･m2) | 0.043 | 0.198 | 0.306 | 0.918 | ||
| Net Weight (kg) (with Soft Top Jaws) | 14 | 25 | 45 | 78 | ||
| Matching Cylinder | S1246 | S1552 | S1875 | S2091 | ||
| Matching Soft Jaws Note) Jaw-mounting bolts are not included. |
Standard Extra Tall |
Standard Extra Tall |
Standard Extra Tall |
Standard Extra Tall |
||
| Matching Hard Jaws Note) Jaw-mounting bolts are not included. |
HB06A1 HB06B1 |
HB08A1 | HB10A1 | HB12N1 | ||
